Technique parameters of SH3000A type ultrasonic bone density analyzer
1, ultrasonic measurement of bone velocity (SOS), no trauma, no radiation, the application of multi population measurement of bone mineral density (baby / children (0-20 years old) Adult / aged (20-100 years old), with other bone research database interface, can also be used for medical research, rapid and simple operation.
2, the digital acquisition module and the standard USB communication technology requirements design, four chip dual transmit and double receive, the use of imported gold standard SOS-Path technology, the collection of data faster and more accurate, product stability is stronger, technology advanced, with the plug with, convenient and flexible;
3, the use of the World Health Organization (WHO) recommended adult T, the world's children's health foundation, the Z database, the calculation parameters are complete: T, Z,%, relative fracture risk (RRF), etc.;
*4, software support 11 languages, and the software can be automatically switched on, with Asian and Chinese people in the Caucasian race and other people of the normal reference values of the database and statistical functions;
5, software measurement scale based on the measurement of SOS values of dynamic changes, measurement range: 2500-4800m/s, the measurement time: single time, 25 seconds, repeat 75 seconds, no need to take off the shoes to prepare, check the large flow, physical examination;
*6, multi site measurement optional (radius and tibia), multi site with the screen can be compared to the probe double socket matching;
X7, built-in Chinese children growth and development model, tracking statistics monitoring children's growth and development index; operation demo demo and operate the practice mode, intelligent automatic judgment measurement of the quality of the data and various sound light prompt;
X8, probe emission work frequency and transducer center frequency is consistent: 1MHz, wide frequency range: 0.85 ~ 1.15MHz, SOS error not exceeding + 1.5%, accuracy is less than or equal to 0.15%, repeat CV is less than or equal to 0.4%;
* 9, powerful computer platform, cloud data processing technology, the operation becomes more scientific and efficient, fully support all Microsoft operating system (you can specify the Microsoft operating system) and more powerful compatibility, built-in workstation (Computer: CPU is greater than or equal to 2.0g, 1g of memory is more than or equal to, the hard disk is greater than or equal to 1TG; 19 inch color LCD display, HP or canon color ink jet printer or printer according to the user specified).
10, improve the case database management system, automatic record, query, classification, backup, reservation, conversion, export, import and other functions, fast and convenient;
11, SQV phantom calibration factory inspection (2750m/s bionic glass) and temperature calibration software, to ensure accuracy and repeatability;
12, the configuration of the special working car, and the car has a ruler function, accurate positioning of the radius / tibia detection part; special with the foot switch can be easy to control the freezing / scanning, measuring easy and convenient;
13, 24 months free warranty, life-long repair, 24 hours rapid response, three months Baohuan, domestic cheap accessories.
14, GB9706.1-2007/GB9706.9-2008 national security standards and national industry standards and testing report;
